SEUIC Scan Tool — scanner control on the TZD

SEUIC Scan Tool is a system tool that allows you to fine-tune your terminal scanner for a specific process: selection, acceptance, inventory, production operations or service. You control not only how the code is read , but also how the data gets into your WMS/ERP/web form – without rewriting programs.

Key features

1)

Barcode settings

— reading parameters

• Security level (protection against “broken” codes).

• IllumPowerLevel and exposure (backlight/camera control).

• Aim mode (aiming), DPM (direct part marking), ILLUMINATION .

• MultiCode limit — limit the number of codes per pass.

• Scan timeout and Low power delay time are timings for stable operation on low charge.

2)

Scan settings

— scanning behavior

• Sound/vibration notifications , Scan LED indicator .

• Append/continuous scan — serial reads without pauses.

3)

Formatting and cleaning data

• Auto Clear — clears the previous result.

• Filter invisible Char — removes invisible characters.

• Convert invisible Char → ASCII — controlled conversion.

• Filter pre/suffix blank — remove spaces at the beginning/end.

• Replace string items — point-to-point replacement of characters/sequences.

4)

Trigger modes and data output

• Triggers: manual , continuous , hands-free , MultiCode .

• Output: Focus (to active field), Broadcast (Android Intent), EmuKey (keyboard emulation), Clipboard (clipboard).

5)

Profiles and roles

• Profile settings : create/switch/delete profiles for different applications and parts of the process.

• Admin Mode : change password, access system settings; User Mode :

  • Normal — work with minimal changes,

  • Guest — without the right to change scan/program settings.

• Factory password for saving the profile : 4007770876 ( be sure to change it after the first launch).

How it works (briefly)

1. Create a profile for a specific program/area.

2. Set Barcode/Scan settings , add filters/formatting .

3. Select output : Focus / Broadcast / EmuKey / Clipboard.

4. Save the profile (new admin password !), enable the desired trigger mode.

5. Deploy the profile to other devices (export/EMM/Stage Now).

Business value

• Fewer errors : clean data thanks to filters and correct suffixes/prefixes.

• Faster execution : MultiCode and continuous scanning reduce steps.

• Uniform standards : Profiles ensure consistent behavior across all locations.

• Low TCO : no need to modify each program — output is managed systemically.

Typical scenarios

• Web WMS/ERP : EmuKey or Focus with Enter/Tab; Broadcast — for your own services.

• Reception with DPM : separate profile with DPM/exposure/backlight.

• Quick selection : MultiCode + Append; whitespace/invisible character filters.

• Hands-free : scan stations, conveyor — minimum interaction.

Security and deployment

• Set your own admin password , use Guest Mode for operators.

• Export configs and deploy via SEUIC EMM/MDM or Stage Now .

• Document profiles as corporate policies (who uses what and where).

FAQ

How is Scan Tool different from Seuic Data Wedge?
Scan Tool is deeper control of the scanner itself (optics/timings/filters/MultiCode) + profiles. Data Wedge is more about routing scans into applications without code. Together, it’s a full stack.

When to choose EmuKey and when Broadcast?
EmuKey — when the form is waiting for “keyboard” input; Broadcast — for your Android services without field focus.

Is it possible to limit the number of codes per pass?
Yes, set a MultiCode limit in your profile.

We see “strange symbols” in the data.
Enable Filter/Convert invisible Char , add Replace string items , remove pre/suffix blank .
